DF518T-120 LED Emergency Driver
Model:DF518T-120
Support LED power rangement:Max 56V, 8A
Emergency Output Power:Max.28W
Input Voltage:AC 120~277V, 50/60HZ
Description
Model | DF518T-120 |
Support LED power rangement | Max 56V, 8A |
Emergency Output Power | Max.28W |
Input Voltage | AC 120~277V, 50/60HZ |
Battery | 11.1V 10000mAh Lithium-ion battery |
Emergency Duration | >90minutes and Customized duration |
Charge Time | ≥24 Hours constant charging |
Self test | Monthly, yearly self-test function |
Working Environment | 0-50℃，65+20%RH |
Charging current | 170-200mA |
Emergency Start Voltage | Support 160V~240V AC input(optional) |
Display settings | green light – the main power, red light – charging, yellow light – fault |
Highlight Features：
◇Specially developed and designed for the US market.
◇This kit can suit maximum 200w light and has max.28w emergency power output!
◇Support for more than 3hours emergency lighting!
◇Designed for in-fixture installation or remote mount, this emergency battery backup is compatible with virtually all LED drivers.
◇Automatical self test, monthly test and annual test function.
◇ETL certificate by UL924 and CSA C22.2
DENGFENG Max.28w reduce power LED emergency driver DF518T-120
Product Description:
1. DF518T-120 LED Emergency Power Kit integrates one high performance lithium-ion battery in red emergency box, designed to output max.28w power as emergency power backup.
2. Dengfeng ETL certificated model DF518T-120 can automatically test light chip's series and adjust output voltage to best match between the inverter and the load, providing max.28w illumination customized.
Highlight Features：
● Auto select (90~280 VAC output)
● Auto selftest with monthly and yearly.
● Maximum Load Power: 200W (0°C to 50°C) CE, Rohs certificates
● Lamps operated: LED fixtures
● Dual Input voltage 120V or 277VAC, 60Hz
● Output Current: Max.300Vdc
● Replaceable and recyclable, Lithium-ion battery and LiFePo4 battery with Max. 5-year life expectancy
● Indoor and Damp location rated
● A testing switch and charging indicator are provided
● This kit uses highly grade smart IC to control circuit, and offer self test, monthly test and annual test function.
